Wombat with a gamepad

VMSZealot

Well-known member
I’ve read the documentation - I understand that the wombat only works with keyboard and mice, and not with gamepad but…
If there are any USB gamepads without analogue sticks, which identify as keyboards (hence requiring no drivers, and hence only requiring configuration in the game itself), I can’t see any reason why they wouldn’t work. So…
Does such a thing exist?

Alternatively, is there an ADB library for teensy (or similar) which give a leg up for developing such a thing? I’d be up for having a crack at developing a gamepad to adb adaptor if such a thing exists…


BetaC

Member
There have been some projects for mapping a gamepad to keyboard inputs, but if I'm not mistaken most of them are centered around PS/2 and or AT keyboards. With that said, I do know there is a Vogons Thread where someone was developing a board to convert genesis and snes controllers to PS/2 that may be helpful.


VMSZealot

Well-known member
Soo… it might be possible to have a doodad that maps a usb gamepad to usb keyboard and then use a wombat. Is that what you mean? It feels a bit clunky though.
is there any good documentation on the ADB protocol and handshaking? I mean, the docs I’ve read say that only one pin carries data - and presumably that’s earthed against the ground plain. What does that look like though? I’m guessing, but I haven’t seen any documentation…
  • Device gets power and sends message to Mac saying I’m here, I’m a keyboard (what header, what ID?)
  • Mac responds with ID for the device to use on the bus
  • Device stores ID and prefixes all future comms with that ID.
does that sound plausible? Where can I find this info?

Also, are there any schematics for any safety concerns, fuses etc, to be included on an ADB device to prevent my homemade tinkerings from giving my precious 68k Mac a very nasty time indeed?


Byrd

Well-known member
Alternatively, is there an ADB library for teensy (or similar) which give a leg up for developing such a thing? I’d be up for having a crack at developing a gamepad to adb adaptor if such a thing exists…

There is a device that converts ADB to SNES/PS1/MD controllers - might be the one to clone. I've got it, but at work can't remember the name of it.


VMSZealot

Well-known member
How does this adaptor help? The hardest part is going to be the software for it, to handle the handshake etc. Without documentation for that, we’re back where we started.
Unless I’m missing something which is entirely probable!


Byrd

Well-known member
This adapter helps as there is software! I'm again at work but will post back, the drivers are on Macintosh Garden.


cheesestraws

Well-known member
(Apropos of nothing at all, every time I scroll past this thread I involuntarily sing its title in my head to the tune of 'tiptoe through the tulips' and it is driving me half mad...)
