See attached file for two row, 9-pin FPD Radius Cable. I made up the Word Document, it's a work in progress. I have a Radius FPD SE Radius Interface Card and Connector. I used an Ohm Meter and best guess from my electronics background to make the chart. I do not have a Radius FPD Monitor (9-Pin Connector) or Macintosh SE to test it.
I got the previous composite analog signal (DB-9 Connector) information from Radius FPD Brochures for the Macintosh II.
Can somebody open their 9-Pin Radius FPD Monitor and take pictures of the inside (BE CAREFUL, HIGH VOLTAGE IS STILL PRESENT, EVEN WHEN THE MONITOR IS UNPLUGGED). I want to see were the wires from the 9-Pin connector are going to? I'm assuming the Monitor ID Pins are shorted to each other or they are wired to a standalone resister (IF THEY ARE MONITOR ID PINS????).
View attachment Radius Cable for FPD 9-Pin Connector.docx
I got the previous composite analog signal (DB-9 Connector) information from Radius FPD Brochures for the Macintosh II.
Can somebody open their 9-Pin Radius FPD Monitor and take pictures of the inside (BE CAREFUL, HIGH VOLTAGE IS STILL PRESENT, EVEN WHEN THE MONITOR IS UNPLUGGED). I want to see were the wires from the 9-Pin connector are going to? I'm assuming the Monitor ID Pins are shorted to each other or they are wired to a standalone resister (IF THEY ARE MONITOR ID PINS????).
View attachment Radius Cable for FPD 9-Pin Connector.docx
